Resistor Color Code

Metal film resistors with less tolernace than carbon film ressitors are marked with five colored rings giving the value and the tolerance. The coding scheme is similar to that of resistors with four rings though an additional digit is shown for the mantissa.

	mantissa					exponent			tolerance
	0 1 2 3 4 5 6 7 8 9	0 1 2 3 4 5 6 7 8 9	0 1 2 3 4 5 6 7 8 9			x 1 x 10 x 100 x 1k x 10k x 100k x 1M x 10M x 0.01 x 0.1 x 0.1 x 0.01			±20% ±1% ±2% ±3% 0...+100% ±0.5% ±0.25% ±0.1% ±5% ±10%
	black brown red orange yellow green blue violet gray white	black brown red orange yellow green blue violet gray white	black brown red orange yellow green blue violet gray white			black brown red orange yellow green blue violet gray white gold silver			black brown red orange yellow green blue violet gold silver
(above table requires JavaScript)

color		mantissa			exponent	tolerance
	black	0	0	0	x 1	±20%
	brown	1	1	1	x 10	±1%
	red	2	2	2	x 100	±2%
	orange	3	3	3	x 1k	±3%
	yellow	4	4	4	x 10k	0...+100%
	green	5	5	5	x 100k	±0.5%
	blue	6	6	6	x 1M	±0.25%
	violet	7	7	7	x 10M	±0.1%
	gray	8	8	8	x 0.01	-
	white	9	9	9	x 0.1	-
	gold	-	-	-	x 0.1	±5%
	silver	-	-	-	x 0.01	±10%
